Line Boring Machine TDG50IMP Diameter 30mm Excavator Bucket Repair

Line Boring Machine TDG50IMP Diameter 30mm Excavator Bucket Repair

Boring range: 55-400mm, 35-400mm(optional) Boring Bar:∅50, ∅30(optional), Boring Stroke: 280mm, Advantage: Modular, Light weight, Efficient, usaully used to repair worn holes and align connecting holes
DTH is a professional exporter of line boring machine tdg50imp diameter 30mm excavator bucket repair, which is also known as one of the most credible such manufacturers and suppliers. You can rest assured to buy or wholesale customized line boring machine tdg50imp diameter 30mm excavator bucket repair which is made in China at low price with our factory.



Advantage of line boring machine:



Portable field boring machine is an efficient and highly versatile piece of equipment that is designed to handle a wide range of boring and machining tasks on site. This machine is mainly used to bore holes, cut threads, and machine surfaces on large and heavy workpieces that cannot be easily moved to a stationary workshop.

The portable field boring machine is widely used in various industries such as aerospace, construction, mining, and power generation. The primary application is to repair or modify worn-out or damaged parts in the field. It is also used to make holes and cut threads for installation of bolts and studs, which are critical for assembling large machinery and equipment.

The machine is designed to work in different orientations - it can be used vertically, horizontally, or at any other angle. It is equipped with powerful motors and high-quality cutting tools that can handle a range of  metal materials.

One of the biggest advantages of using a portable field boring machine is that it eliminates the need to transport large and heavy workpieces to a workshop. This not only saves time but also reduces costs associated with transportation and handling. Additionally, it allows the workpiece to remain in its original location, which reduces the risk of damage during transportation.

The portable field boring machine is an essential tool for many industries that require precise and efficient boring and machining on-site. It enables technicians to perform critical repairs and modifications to large workpieces without the need to transport them to a workshop, which ultimately improves productivity and reduces costs.



TDG50IMP 8

TDG50IMP 9

TDG50IMP 10

TDG50IMP 11

Specifications:

Boring Diameter 55 – 400mm(standard) 35-400mm(optional)
Boring Stroke 280mm
Feed Rate  0-0.5mm/rev
Bar RPM 0-49、49-98
Drive Power Unit 110V/230V, 50/60Hz, 1800W
Boring Bar ∅50×1828mm,∅50×2438mm
  ∅30×1200mm
Shipping Weight 125kg



Specification:

TDG50 Line Boring TDG50PLUS Line Boring
Boring Diameter:  55-300mm Boring Diameter: 40-300mm
Boring Stroke: 280mm Boring Stroke:280mm
Feed Rate:  0-0.5mm/rev Feed Rate:  0-0.5mm/rev
Bar RPM: 0-49、49-98 Bar RPM: 0-49、49-98
Drive Power Unit: Single phase,110V/230V, 50/60Hz, 1800W Drive Power Unit: Single phase,110V/230V, 50/60Hz, 1800W
Boring Bar:∅50×1828mm Boring Bar:∅50×1828mm,∅35×1200mm
Shipping Weight:98kg Shipping Weight:125kg
